Description

MODERN RESISTANT AND EASY TO USE

The Level Regulator – RNC 1002, made in Portugal, is a Certified product for level control in sewage, drainage, and pumping stations in general.
Main Features
Max. Voltage
250Vac / 50Hz

Nominal Current
10(3) A

Max working pressure (+20ºC)
4 bar (400kPa)

Temperature
Mín. 0ºC | Máx. +60ºC

Specific weight (liquids)
0,95 – 1,10 g/cm3

Estanquicity
IP 68
Materials
Casing: Polypropylene
Counter weight (2 parts): Zamac
Cable: H05VV-F 3 x 1mm2

Standard available cable lengths
5, 6, 8, 10, 15, 20 meters
(others upon request)

Weight and dimensions
Casing lenght: 160mm
DMax. Casing diameter : 100mm

Aprox. Weight (with 6 m cable)
1,3 Kg
